Freeze drying machine fruit veggies flowers vacuum drying machine

2018-11-13 20:24
1512619339667085631


Technical Details:

Item

Spec.

Model

FD-10R

Available freeze drying area

10.8square meters

Drying House

Shelf: 9+1 layers

Shelves size:1000*1200mm

Shelves temperature: -40 to +100C

Material trays: 18pcs

Material trays size: 1000*600mm

Condenser Capacity

100kgs/24hrs

Condenser temperature

-65C

Machine vacuum degree

≤ 10.0 Pa

Power install

25kwh

Install size

3350mm*1500mm*2250mm

Voltage

380V/50-60Hz/3p

Operate weight

About 4000kgs

Working noise

<65db

Machine design standard

HACCP, GB

Main material

AISI304 + Aluminum

Controller system

PLC+Touch screen

Related Products



FD-5R

FD-10R

FD-20R

Shelf area

5sq.m

10sq.m

20 sq.m

Shelf size

600*1200mm

1000*1200mm

600*2150mm x2

Shelf number

7+1

9+1

8+1

Shelf temp.

-40 to +120C

-40 to +120C

-40 to +120C

Condenser temp.

-65C

-65C

-65C

Condenser capacity

50kgs

100kgs

200kgs

Vacuum

<10Pa

<10Pa

<10Pa

Install power

18kwh

25kwh

68kwh
